November, 30th 2025•14 min read

Designing Validation Architecture with Value Objects in Orymu

Designing sign up validation with value objects so forms stay honest, testable, and maintainable as the app grows.

Ahmad Fikril

Ahmad Fikril

November, 30th 2025

Designing Validation Architecture with Value Objects in Orymu

Designing Validation Architecture with Value Objects in Orymu

1. TL;DR

In my earlier Flutter projects I already used Clean Architecture, but all validation logic lived inside GetX controllers. As the forms got bigger, those controllers turned into long, stateful classes that mixed UI state, validation rules, and mapping to request entities. It worked, but it was fragile and hard to change.

When I started Orymu I decided to clean this up. I moved the validation rules into domain level value objects, introduced a shared ValueFailure model, and used Bloc for presentation. Blocs now use value objects for real time feedback, and use cases re validate everything as a final gate before touching repositories. This keeps the rules in one place, gives better UX, and makes the sign up flow much easier to reason about and test.

2. Context

Before Orymu, most of my production work was built with:

  • Flutter as the main stack.
  • GetX for routing and state management.
  • Clean Architecture in the sense of separate presentation, domain, and data layers.

The apps were not small. They had complex flows like financial dashboards, tuition payments, savings, and multi step onboarding. Because of that, I was already careful about layer boundaries and repositories. However, my validation approach never evolved as much as the rest of the architecture. I usually kept all form validation logic inside GetX controllers.

When I started Orymu, which is an AI powered reading and flashcard app, I wanted to use the project to refine some parts of my architecture, not just copy the last setup. One of the biggest pains I wanted to fix was how I handled validation in big forms like sign up.

I also decided to switch to Bloc for presentation. Bloc gave me a clearer pattern around events, states, and side effects, which helped me separate UI concerns from validation and domain logic.

3. My Role

I designed and implemented the validation architecture for Orymu. That included:

  • Defining value objects for core inputs like email, password, username, and display name.
  • Designing the ValueFailure model and the mapping to user facing error messages.
  • Wiring those value objects into Blocs for real time field validation.
  • Adding a final validation gate inside use cases before they call repositories.
  • Designing and implementing the sign up flow to use this pattern end to end.

The goal was not just to make one screen cleaner, but to build a pattern I could reuse for other auth flows, onboarding, and future forms.

4. Problem and Constraints

4.1 How validation used to look

In previous projects I kept everything inside the controller. For example, a complex registration or data entry controller would:

  • Own many TextEditingController and Rx fields.
  • Contain methods like validateEmail, validatePhoneNumber, validateIncome, and validateRequiredField.
  • Build a list of validationErrors by calling all these methods.
  • Expose computed getters like isPersonalDataValid and canConvertToEntity.
  • Build the final request entity manually in a toEntity() method.

The example below is simplified, but the pattern is similar to what I used:

class CreateSomethingController extends GetxController {
  String email = '';
  String phone = '';

  String? validateEmail(String? email) {
    /* regex and messages */
  }

  String? validatePhone(String? phone) {
    /* length, prefix rules */
  }

  List<String> get validationErrors {
    final errors = <String>[];
    final emailError = validateEmail(email);
    if (emailError != null) errors.add(emailError);
    final phoneError = validatePhone(phone);
    if (phoneError != null) errors.add(phoneError);
    return errors;
  }

  bool get canConvertToEntity => validationErrors.isEmpty;

  RequestEntity toEntity() {
    /* read from controllers and build request */
  }
}

On real screens this became much bigger, with many more fields and rules. The CreateMustahikIndividualController from one of my previous projects is a good example. It contains:

  • Dozens of fields and options.
  • A long toEntity() method that converts internal state to a request.
  • A set of validateXxx functions plus a validationErrors list that stitches them together.

It works, but everything lives in one class.

4.2 Why this became a problem

The pattern above created a few concrete problems for me:

  • The controller kept growing. It was responsible for UI state, validation rules, formatting, and mapping to entities. Adding a new field or changing a rule always meant touching this large, mixed class.
  • Validation was tightly coupled to widgets. The rules directly read from TextEditingController and Rx state. There was no reusable type like EmailAddress or PhoneNumber that I could share across flows.
  • There was no real final gate in the domain. The controller tried to be the last line of defense with canConvertToEntity, but nothing enforced that every caller had to respect it before calling toEntity().
  • Testing validation properly required instantiating the whole controller, wiring controllers and Rx values, then calling validation methods. I could not test the business rules as small focused units.

When I started thinking about Orymu sign up and other auth flows, I realized I needed a better place for the rules. I wanted validation to be part of the domain, not just a side effect of the UI controller.

4.3 Constraints and goals

I put a few constraints on the new approach:

  • Keep Clean Architecture boundaries intact. Validation rules should live in the domain layer, not in widget code.
  • Give users good UX. I still wanted real time inline errors as they type.
  • Stay defensive. The system should not rely on the UI alone. Use cases should never accept obviously invalid inputs.
  • Keep things testable. I wanted to be able to write small, deterministic tests for the value objects without involving widgets or controllers.

5. Options Considered

When I redesigned validation for Orymu I thought through a few directions.

Option 1: Keep validation in Bloc or controller, but organize it better

I could have kept all the rules inside the Bloc or a controller and just tried to structure it more nicely. For example, I could group validation methods into a helper class or split them across mixins.

This would have kept all logic in the presentation layer. It might make the Bloc a bit cleaner than my old GetX controllers, but the rules would still not live in the domain, and use cases would still have to trust the UI.

Option 2: Introduce a validation service per form

Another idea was to create a per form validation service, for example SignUpValidator, that the Bloc and use case could both call.

This looked better than having everything in the Bloc, but it still treated validation as a separate service rather than part of the domain model. I would still need to invent error types and decide how to pass user friendly messages around.

Option 3: Move rules into domain value objects

The option that felt most aligned with Clean Architecture was to introduce value objects:

  • Each field that has business rules gets its own value object, for example EmailAddress, Password, Username, and DisplayName.
  • Creation happens through a factory or static method like EmailAddress.create(input).
  • The method returns Either<ValueFailure, VO>, where ValueFailure is a small union type that describes why the value is invalid.

This approach gives me:

  • A single source of truth for each field rule.
  • A simple, reusable error model with a userMessage mapper.
  • A way for both Bloc and use case to rely on the same rules without duplication.

I decided to go with option 3 and build the Orymu sign up flow on top of value objects. It fits the way I want to structure the domain: the rules live next to the concepts they protect, the presentation layer just consumes them, and use cases still act as a final gate before repositories. Value objects are also a common pattern in Domain Driven Design and industry practice, so I was not inventing something ad hoc just for this app.

For a deeper explanation of value objects in general, I like Vladimir Khorikov's article Value Objects explained.

6. Chosen Solution

6.1 Value objects and failures

I started by defining value objects in the auth domain:

  • EmailAddress with an EmailAddress.create(String input) factory.
  • Password with a Password.create(String input) that enforces:
    • Minimum length.
    • At least one lowercase, one uppercase, and one digit.
  • ConfirmPassword that compares the original and confirmation values.
  • Username and DisplayName with their own length and format rules.

Each create method returns Either<ValueFailure, VO>. ValueFailure is a Freezed union that encodes concrete reasons like invalidEmail, shortPassword, missingUppercase, passwordsDoNotMatch, and empty.

I added a userMessage extension on ValueFailure so each failure maps to a human readable error message. This keeps validation messages in one place and avoids hard coded strings spread across widgets.

A simplified example of the EmailAddress value object in Orymu looks like this:

class EmailAddress {
  final String value;
  const EmailAddress._(this.value);

  static Either<ValueFailure, EmailAddress> create(String input) {
    final trimmed = input.trim();
    final regex = RegExp(r'^[^\\s@]+@[^\\s@]+\\.[^\\s@]+');
    if (regex.hasMatch(trimmed)) {
      return right(EmailAddress._(trimmed));
    } else {
      return left(ValueFailure.invalidEmail(input));
    }
  }
}

And the Username value object looks like this:

class Username {
  final String value;
  const Username._(this.value);

  static Either<ValueFailure, Username> create(String input) {
    final trimmed = input.trim();
    if (trimmed.isEmpty) {
      return left(ValueFailure.empty(input));
    }
    if (trimmed.length < 3) {
      return left(ValueFailure.shortUsername(input));
    }
    if (trimmed.length > 20) {
      return left(ValueFailure.longUsername(input));
    }
    final validFormat = RegExp(r'^[a-zA-Z0-9_]+$');
    if (!validFormat.hasMatch(trimmed)) {
      return left(ValueFailure.invalidUsernameFormat(input));
    }
    return right(Username._(trimmed));
  }
}

The rules live inside the value object, and callers only see a success value or a ValueFailure.

6.2 Two layers of validation

The sign up flow uses these value objects in two places.

  1. Field level in the Bloc
    The AuthRegisterBloc calls value object factories on every EmailChanged, PasswordChanged, ConfirmPasswordChanged, and DisplayNameChanged event. It stores the result as simple strings in the state:

    • If the value object returns left(failure) the Bloc stores failure.userMessage as emailError or passwordError.
    • If it returns right(vo) the error field is set to null.

    In code this looks like:

    void _onEmailChanged(EmailChanged event, Emitter<AuthRegisterState> emit) {
  final emailResult = EmailAddress.create(event.email);
  emit(state.copyWith(
    email: event.email,
    emailError: emailResult.fold(
      (failure) => failure.userMessage,
     (_) => null,
   ),
 ));
}

Inline email validation state

The UI binds errorText of each field to these state properties and rebuilds via BlocBuilder. This gives users immediate, field specific feedback without duplicating rules in the widget.

  1. Submit level in the use case
    The RegisterUserUseCase treats the same value objects as a final gate before the repository:

    • It calls EmailAddress.create(request.email), Password.create(request.password), and DisplayName.create(request.displayName).
    • It collects any failures into a list of ValidationError objects with field, message, and code.
    • If there are any errors, it returns AuthFailure.validation(errors) instead of calling the repository.
    • If validation passes, it calls _repository.register(request) and continues the flow.

    A simplified version of the use case gate is:

    Future<Either<AuthFailure, UserEntity>> call(
  RegisterRequestEntity request,
) async {
  final email = EmailAddress.create(request.email);
  final password = Password.create(request.password);
  final displayName = DisplayName.create(request.displayName);

  final errors = <ValidationError>[];

  email.fold(
    (f) => errors.add(ValidationError(
      field: 'email',
      message: f.userMessage,
      code: 'invalid_email',
    )),
    (_) {},
  );

  password.fold(
    (f) => errors.add(ValidationError(
      field: 'password',
      message: f.userMessage,
      code: 'weak_password',
    )),
    (_) {},
  );

  displayName.fold(
    (f) => errors.add(ValidationError(
      field: 'display_name',
      message: f.userMessage,
      code: 'invalid_display_name',
    )),
    (_) {},
  );

  if (errors.isNotEmpty) {
    return left(AuthFailure.validation(errors));
  }

  return _repository.register(request);
}

This pattern guarantees that repositories only see inputs that passed the domain rules, even if the presentation layer has a bug.

6.3 Error propagation back to the UI

When the use case returns AuthFailure.validation, the Bloc knows how to map each ValidationError back into field errors:

  • It iterates over the validationErrors list.
  • It switches on error.field (for example email, password, display_name, or confirm_password).
  • It sets the corresponding emailError, passwordError, displayNameError, or confirmPasswordError in the state.

This way server side or final gate validation errors still surface on the correct fields in the form.

A simplified version of that mapping is:

void _handleAuthFailure(
  AuthFailure failure,
  Emitter<AuthRegisterState> emit,
) {
  failure.when(
    validation: (validationErrors) {
      String? emailError;
      String? passwordError;
      String? displayNameError;
      String? confirmPasswordError;

      for (final error in validationErrors) {
        switch (error.field?.toLowerCase()) {
          case 'email':
            emailError = error.message;
            break;
          case 'password':
            passwordError = error.message;
            break;
          case 'display_name':
            displayNameError = error.message;
            break;
          case 'confirm_password':
            confirmPasswordError = error.message;
            break;
        }
      }

      emit(state.copyWith(
        status: AuthFormStatus.failure,
        emailError: emailError,
        passwordError: passwordError,
        displayNameError: displayNameError,
        confirmPasswordError: confirmPasswordError,
        message: null,
      ));
    },
    // other failures (network, server, etc.) map to generic messages
    network: () => emit(state.copyWith(
      status: AuthFormStatus.failure,
      message: 'Please check your internet connection',
    )),
    emailTaken: () => emit(state.copyWith(
      status: AuthFormStatus.failure,
      emailError: 'This email is already registered',
      message: 'This email is already registered',
    )),
    // ...
  );
}

6.4 Flow comparison

To make the contrast clearer, this is how the old GetX style flowed:

Mermaid diagram loading…

All validation, eligibility checks, and request building happen inside the controller.

In Orymu the flow looks like this:

Mermaid diagram loading…

Here the Bloc and use case are both clients of the same value objects, and the domain layer has the final say before any repository calls. The colors correspond to three flows:

  • Blue - real time loop while typing
    Every time the user edits a field, the UI dispatches events like EmailChanged. The Bloc calls the relevant value object create methods, updates AuthRegisterState with emailError or passwordError, and the form rebuilds with inline errors. No repository calls happen here.

  • Green - submit with successful validation
    When the user taps "Sign up", the Bloc builds a RegisterRequestEntity and calls RegisterUserUseCase. The use case re validates with value objects as a final gate. If every VO passes, the use case calls the AuthRepository, which sends the request to the API.

  • Orange - submit with validation errors
    If the use case finds invalid input at the final gate, it returns AuthFailure.validation with a list of ValidationError. The Bloc maps those errors back into AuthRegisterState fields like emailError and passwordError, and the UI shows them on the form. The repository is never called in this path.

7. Impact

Moving validation into value objects and adding a final gate in use cases had several concrete effects on Orymu:

  • Thinner Blocs and predictable presentation logic
    The AuthRegisterBloc focuses on orchestrating events, updating state, and calling the use case. The validation rules live in value objects, which keeps the Bloc easier to read and maintain.

  • Single source of truth for rules and messages
    Email, password, username, and display name rules now live in one place in the domain. If I need to tweak a password policy or adjust a message, I change the value object and ValueFailure mapping instead of searching through widgets.

  • Real time UX and defensive backend calls at the same time
    I did not have to choose between great UX and strict domain validation. Blocs give immediate, inline errors while use cases still guard repositories from invalid data.

  • Better testability
    I can test each value object with small unit tests. I can also write tests for the use case that verify it returns AuthFailure.validation when given invalid inputs. I do not need to spin up a full UI controller to prove that rules work.

  • Clearer mental model for future features
    The pattern scales well. When I add new flows or forms, the first question I ask is whether this field deserves its own value object. That keeps validation and domain modeling part of the conversation, instead of an afterthought.

8. What I Learned

Working through value objects and validation in Orymu changed how I think about forms and business rules:

  • I now treat validation as part of the domain, not just a UI concern. Fields like email and password deserve real types, not just strings with ad hoc checks.
  • Having a final gate in use cases makes me more confident that repositories operate on valid data, even if the UI code is imperfect.
  • Good UX and good architecture do not have to be in conflict. With value objects I can support real time feedback and still keep the rules centralized and testable.
  • Coming from a GetX background, moving to Bloc and value objects helped me separate responsibilities more clearly in the presentation layer. I spend less time fighting large controllers and more time reasoning about the domain and flows.

This was my first project that fully embraced value objects for validation, and it is a pattern I want to carry forward into future apps, especially where forms and rules are central to the product.

FlutterArchitectureValidation
